Wacker Neuson BS60-4As Tamping Rammer with Honda engine and 11 in Ramming Shoe

Wacker Neuson BS60-4As Tamping Rammer with Honda engine and 11 in Ramming Shoe

$2,999.99
$2,999.99
Sale Sold out
  • Wacker Neuson BS60-4As Tamping Rammer with Honda engine and 11 in Ramming Shoe
1 1
Wacker Neuson

Wacker Neuson BS60-4As Tamping Rammer with Honda engine and 11 in Ramming Shoe

Wacker Neuson BS60-4As Tamping Rammer with Honda engine and 11 in Ramming Shoe

Danse #: BS60-4As
Mfr #: 5100030605
$2,999.99
$2,999.99
Sale Sold out
View full details

Description

4 stroke vibratory rammer with 11-inch (280mm) shoe for soil compaction, Honda GX engine

  • 4 stroke rammer with Honda GXR120 engine
  • Convenient operation with only one single lever for start, stop and idling
  • Large stroke, high percussion rate and high impact force with quick travel speed for a high level of performance
  • Specially designed and developed 4-stage air filter system provides for longer operating time and greater durability
  • With operating hours counter
  • Protection against low oil level: Unit does not start if the sensor detects a low oil level.



OPERATING FLUIDS Imperial Metric
Lubrication intervall 250 h 250 h
Oil volume 0,238 gal US 0,900 l
Oil specification SAE 10W-40 SAE 10W-40


ENGINE

 Imperial Metric
Utilizable tank capacity SAE 10W-30 SAE 10W-30
Fuel management Carburettor Carburettor
Engine operating mode four-stroke four-stroke
Carburettor type dry air filter dry air filter
Operating Engine speed 4.100 1/min 4.100 1/min
Fuel consumption 0,3 GPH US 1,7 lb/h 1,00 L/hr 0,75 kg/h
Idling speed 1.850 1/min 1.850 1/min
Battery Size BCI Group Honda Honda
Engine speed (max. torque) EPA Phase2 & EU2002/88/EC EPA Phase2 & EU2002/88/EC
Standard (Power max.) SAE J1349 SAE J1349
Standard (Effective power) ISO 3046-1 ISO 3046-1
Nominal Engine speed 4.200 1/min 4.200 1/min
Electrode distance 0,024 - 0,028 " 0,6 - 0,7 mm
Effective power 3,6 hp 2,7 KW
Oil filling max. 0,1 gal US 0,30 l
Oil consumption (full load) 0,1 gal US 0,30 l
Air cleaner dry air filter dry air filter
Cooling air cooling air cooling
Exhaust-gas limit EPA TIER II EPA TIER II
Oil specification SAE 10W-40 SAE 10W-40
Starter type Recoil starter Recoil starter
Operating power 3,6 hp 2,7 KW
Oil filling min. 0,1 gal US 0,30 l
Engine type Gasoline engine

Warranty

Danse Equipment Company assures warranty of one year from the date of purchase on any products purchased, against defects in workmanship or materials under normal use, unless otherwise specified. Furthermore, Danse Equipment will pass any additional manufacturer’s warranty privileges to the purchaser. Any equipment damaged or abused will be voided of warranty and will not be covered. For information on a specific manufacturer’s warranty, please contact us at warranty@danseusa.com with the date, invoice and product details.
