CC1100 Frame Base Assembly Parts

CC1100 Frame Base Assembly Parts

Skip to product information
1 of 1
100% genuine product
Authorised dealer
Ref. Product details Price Qty Action
1
6048260 Frame Base for CC1100 CONCRETE SAW
$405.90
2
6048028 Rear Axle Assembly (includes #3 - #7) for CC1100 Concrete Saw Core Cut by Diamond Products
$66.26
3
2900040 Capscrew, Hex Hd., 3/4"-10 x 4-1/2" for CC1100 Concrete Saw Core Cut by Diamond Products
$8.83
4
2900003 Flat Washer 3/4" SAE for CC5555-3 Concrete Saw Core Cut by Diamond Products
$3.99
5
2500411 Wheel, 8" for CC1100 Concrete Saw Core Cut by Diamond Products
$69.95
6
2900041 Hex Nut, 3/4"-10 for CC1100 Concrete Saw Core Cut by Diamond Products
$3.99
7
2900042 Lock Washer, 3/4" Split for CC1100 Concrete Saw Core Cut by Diamond Products
$3.99
8
6048295 Belt Adjustment Shaft for CC1100 Concrete Saw Core Cut by Diamond Products
$43.61
9
2900014 Flat Washer 3/8" SAE for CC5555-3 Concrete Saw Core Cut by Diamond Products
$2.99
10
2900006 Lock Washer 3/8" Split for CC5555-3 Concrete Saw Core Cut by Diamond Products
$2.99
11
2900033 Hex Nut 3/8-16 for CC5555-3 Concrete Saw Core Cut by Diamond Products
$2.99
14
2900018 Lock Nut 3/8-16 Nylon for CC5555-3 Concrete Saw Core Cut by Diamond Products
$2.99
55
6048279 Pointer Assembly (includes #9, #14, #56, #57) for CC1100 Concrete Saw Core Cut by Diamond Products
$73.12
56
6048280 Pointer Only for CC1100 Concrete Saw Core Cut by Diamond Products
$64.75
57
2900013 Cap Screw Hex Hd. for CC5555-3 Concrete Saw Core Cut by Diamond Products
$2.99
88
6048273 Belt Guard for CC1100 Concrete Saw Core Cut by Diamond Products
Call for Price call for price call for price
89
2900021 Machine Screw, Round Hd., #10-24 x 3/8" for CC1100 Concrete Saw Core Cut by Diamond Products
$2.99
90
2900038 Lock Washer, #10 Split for CC1100 Concrete Saw Core Cut by Diamond Products
$2.99
91
2900005 Cap Screw Hex Hd. for CC5555-3 Concrete Saw Core Cut by Diamond Products
$2.99
92
6048272 Belt Guard Mounting Plate for CC1100 Concrete Saw Core Cut by Diamond Products
$52.38
View full details

Frequently asked questions

How do I use this diagram?

Match the Ref. # on the diagram to the row in the parts list at the right. Click a part name to see details, price, and add it to cart.

How do I make sure a part fits my machine?

Confirm your model/series and serial number range on the product page. Many
manufacturers have serial breaks, when in doubt, share your model and serial with us and we’ll verify fit.

What do the Ref. numbers and quantities mean?

The Ref. # points to the callout on the drawing. Qty shows how many of that item your
machine uses. Parts are sold individually unless noted as a kit.

Are these genuine parts?

Yes, we supply genuine OEM parts for all our brands. If a part has an approved
replacement, we ship the latest superseded revision.

Why does my original part number look different?

Manufacturers often supersede numbers. Our pages list the current orderable number and show older numbers in the description when available. Your old number will cross-reference to the correct part.

I can’t find a part in this diagram, can you still get it?

Yes. Some items are not pictured or are shared with other assemblies. Send us the model, serial, and a description (or photo) and we’ll locate it.
