Description
CC1800XL 14' to 20" Gasoline Self Propelled Concrete Walk Behind Saw (Briggs Vanguard 16HP) by Core Cut Diamond Products
Motor -
Briggs & Stratton Vanguard 16HP
*Self Propelled*
| SPECIFICATIONS - CC1800XL |
| BLADE CAPACITY |
14 INCHES TO 20 INCHES |
| MAXIMUM CUTTING DEPTH |
4 5/8" to 7 5/8" |
| ENGINE |
BRIGGS & STRATTON VANGUARD 16HP |
| HORSEPOWER |
16HP |
| WEIGHT |
380 TO 460 LBS |
CC1800XL GASOLINE SELF PROPELLED CONCRETE WALK BEHIND SAW
Main Features -
- Different models available with varying power capacity
-
Maximum cutting depth of 7 5/8" achievable with a 20" blade
- Electric start available for Honda and Briggs Engines
- The blade shaft drives on 3 belts for a 11.7HP engine and 4 belts for higher power engine models
- Blade mounting for both right and left sides available
-
Drive speed range of 0-80 feet per minute
-
Blade shaft diameter of 1-1/4" with high blade shaft RPM of 2,600
- Both left and right side sawing options are available
- Screw feed raise and lower feature for easier operation
- Lifting hook standard on all models
- Self-aligning blade shaft bearings
| OTHER MODELS FOR CC5049DC FRONT PIVOT WALK BEHIND SAW |
| MOTOR OPTIONS |
POWER |
STARTER |
WEIGHT (LBS) |
MAX CUTTING DEPTH |
BALDESHAFT RPM |
| GX390 |
11.7 HP |
RECOIL |
380 |
7 - 5/8" |
2,600 |
| GX390 E/S |
11.7 HP |
ELECTRIC START |
395 |
7 - 5/8" |
2,600 |
| BRIGGS 2100 |
420 CC |
RECOIL |
400 |
7 - 5/8" |
2,600 |
| BRIGGS VANGUARD |
16 HP |
RECOIL |
380 |
7 - 5/8" |
2,600 |
| HONDA GX630A |
20.8 HP |
ELECTRIC START |
470 |
7 - 5/8" |
2,600 |
| BRIGGS VANGUARD E/S |
23 HP |
ELECTRIC START |
460 |
7 - 5/8" |
2,600 |
