CC1800XL Briggs 23HP Gasoline Concrete Walk Behind Saw (14' to 20") by Core Cut Diamond Products

CC1800XL Briggs 23HP Gasoline Concrete Walk Behind Saw (14' to 20") by Core Cut Diamond Products

$10,067.31
$10,067.31
Sale Sold out
  • CC1800XL Briggs 23HP Gasoline Concrete Walk Behind Saw (14' to 20") by Core Cut Diamond Products
1 1
Diamond Products

CC1800XL Briggs 23HP Gasoline Concrete Walk Behind Saw (14' to 20") by Core Cut Diamond Products

CC1800XL Briggs 23HP Gasoline Concrete Walk Behind Saw (14' to 20") by Core Cut Diamond Products

Danse #: 5801218
Mfr #: 5801218
$10,067.31
$10,067.31
Sale Sold out
View full details

Description

CC1800XL 14' to 20" Gasoline Concrete Walk Behind Saw (Briggs Vanguard 23HP) by Core Cut Diamond Products

Motor -

Briggs & Stratton Vanguard 23HP

SPECIFICATIONS - CC1800XL
BLADE CAPACITY 14 INCHES TO 20 INCHES
MAXIMUM CUTTING DEPTH 4 5/8" to 7 5/8"
ENGINE BRIGGS & STRATTON VANGUARD 16HP
HORSEPOWER  23HP
WEIGHT 380 TO 460 LBS


CC1800XL GASOLINE SELF PROPELLED CONCRETE WALK BEHIND SAW

Main Features -

  • Different models available with varying power capacity
  • Maximum cutting depth of 7 5/8" achievable with a 20" blade
  • Electric start available for Honda and Briggs Engines
  • The blade shaft drives on 3 belts for a 11.7HP engine and 4 belts for higher power engine models
  • Blade mounting for both right and left sides available
  • Drive speed range of 0-80 feet per minute
  • Blade shaft diameter of 1-1/4" with high blade shaft RPM of 2,600
  • Both left and right side sawing options are available
  • Screw feed raise and lower feature for easier operation
  • Lifting hook standard on all models
  • Self-aligning blade shaft bearings

OTHER MODELS FOR CC5049DC FRONT PIVOT WALK BEHIND SAW
MOTOR OPTIONS POWER STARTER WEIGHT (LBS) MAX CUTTING DEPTH BALDESHAFT RPM
GX390 11.7 HP RECOIL 380 7 - 5/8" 2,600
GX390 E/S 11.7 HP ELECTRIC START 395 7 - 5/8" 2,600
BRIGGS 2100 420 CC RECOIL 400 7 - 5/8" 2,600
BRIGGS VANGUARD 16 HP RECOIL 380 7 - 5/8" 2,600
HONDA GX630A 20.8 HP ELECTRIC START 470 7 - 5/8" 2,600
BRIGGS VANGUARD E/S 23 HP ELECTRIC START 460 7 - 5/8" 2,600
