CC3538 JK 35Hp Kohler EFI Throttle Cable Assembly

CC3538 JK 35Hp Kohler EFI Throttle Cable Assembly

  • CC3538 JK 35Hp Kohler EFI Throttle Cable Assembly
1 1
100% genuine product
Authorised dealer
Ref. Product details Price Qty Action
1
2500376 Vernier Throttle Cable for CC3500J Concrete Saw Core Cut by Diamond Products
$202.00
2
2500940 Throttle Cable Clamp for CC3538JK (EFI) Concrete Saw Core Cut by Diamond Products
$11.33
3
2900015 Machine Screw, Hex Hd., #10-24 x 3/4" for CC3538JK (EFI) Concrete Saw Core Cut by Diamond Products
$2.99
4
2900017 Lock Nut, #10-24 Nylon for CC3538JK (EFI) Concrete Saw Core Cut by Diamond Products
$2.99
5
2500999 Clamp, 5/8" Hose for CC3538JK (EFI) Concrete Saw Core Cut by Diamond Products
$3.99
6
2900341 Cap Screw, Hex Hd., M6-1.0 x 16mm for CC3538JK (EFI) Concrete Saw Core Cut by Diamond Products
$2.99
7
2900009 Flat Washer, 1/4" SAE for CC3538JK (EFI) Concrete Saw Core Cut by Diamond Products
$2.99
8
2900302 Lock Nut, M6-1.0 Nylon Insert for CC3538JK (EFI) Concrete Saw Core Cut by Diamond Products
$2.99
View full details
