CC4144DXL-3 Wiring Diagram

CC4144DXL-3 Wiring Diagram

  • CC4144DXL-3 Wiring Diagram
1 1
100% genuine product
Authorised dealer
Ref. Product details Price Qty Action
1
2800073 Battery Cable, Positive (Red) for CC3535 Concrete Saw Core Cut by Diamond Products
$119.79
3
2800095 Solenoid Cable, 14" Positive (Red) for CC3500J Concrete Saw Core Cut by Diamond Products
$46.84
4
6048092 Battery Cable Assy., Black for CC190PRO Concrete Saw Core Cut by Diamond Products
$49.53
6
2600540 Electro/Hydraulic Pump Unit for CG-1 MINI-GROOVER Core Cut by Diamond Products
Call for Price call for price call for price
9
2800372 Pushbutton Switch (B&G) for CC5555-3 Concrete Saw Core Cut by Diamond Products
$81.78
10
2800373 Pushbutton Switch (B&W) for CC5555-3 Concrete Saw Core Cut by Diamond Products
$86.09
13
2801367 E-Stop Switch for CC3500J Concrete Saw Core Cut by Diamond Products
$81.00
16
2705000 Ignition Keys Only (Pair) for CC5555-3 Concrete Saw Core Cut by Diamond Products
$32.00
2
2800072 Ground Cable, Negative (Black) fits CC4144DXL-3 by Core Cut Diamond Products
$85.00
5
2800561 Battery, 12 Volt Group Size 26 fits CC4144DXL-3 by Core Cut Diamond Products
$318.00
7
2703228 Solenoid Switch 12VDC fits CC4144DXL-3 by Core Cut Diamond Products
$227.70
8
2703229 Mounting Strap fits CC4144DXL-3 by Core Cut Diamond Products
$47.35
11
6010893 Tachometer / Hour meter (VDO) Calibrated fits CC4144DXL-3 by Core Cut Diamond Products
$238.59
12
2800925 Fuse Panel, 6 Circuit fits CC4144DXL-3 by Core Cut Diamond Products
$36.67
14
2800144 Relay, 50 Amp, 12V, SPDT fits CC4144DXL by Core Cut Diamond Products
$26.65
15
2800857 Fuse, 15 Amp fits CC4144DXL-3 by Core Cut Diamond Products
$3.99
15
2800856 In-Line Fuse Holder fits CC4144DXL by Core Cut Diamond Products
$13.42
16
2700501 Ignition Switch, CC4144D fits CC4144DXL-3 by Core Cut Diamond Products
$104.38
17
2800855 Wire Harness, Lamp Timer fits CC4144DXL-3 by Core Cut Diamond Products
Call for Price call for price call for price
18
2705003 Cluster Gage, 4 Warning Light fits CC4144DXL-3 by Core Cut Diamond Products
$330.66
View full details

Frequently asked questions

How do I use this diagram?

Match the Ref. # on the diagram to the row in the parts list at the right. Click a part name to see details, price, and add it to cart.

How do I make sure a part fits my machine?

Confirm your model/series and serial number range on the product page. Many
manufacturers have serial breaks, when in doubt, share your model and serial with us and we’ll verify fit.

What do the Ref. numbers and quantities mean?

The Ref. # points to the callout on the drawing. Qty shows how many of that item your
machine uses. Parts are sold individually unless noted as a kit.

Are these genuine parts?

Yes, we supply genuine OEM parts for all our brands. If a part has an approved
replacement, we ship the latest superseded revision.

Why does my original part number look different?

Manufacturers often supersede numbers. Our pages list the current orderable number and show older numbers in the description when available. Your old number will cross-reference to the correct part.

I can’t find a part in this diagram, can you still get it?

Yes. Some items are not pictured or are shared with other assemblies. Send us the model, serial, and a description (or photo) and we’ll locate it.

Is there a warranty on these parts?

Yes. DanseUSA passes the manufacturer’s warranty to you. Coverage applies to defects in materials and workmanship under normal use for 30 days from the purchase date, in line with the manufacturer’s warranty policy. Terms can vary by brand; the product page reflects
the applicable policy. If a claim is needed, we’ll help coordinate with the manufacturer.

Do you accept returns?

Yes, most new, uninstalled items can be returned under our standard policy. Please see our Returns & Refunds Policy for eligibility, timeframes, and any exceptions.
