CC6160D Depth Stop Assembly

CC6160D Depth Stop Assembly

  • CC6160D Depth Stop Assembly
1 1
100% genuine product
Authorised dealer
Ref. Product details Price Qty Action
1
6010927 Depth Stop Weldment, 22" for CC6160D Rear Pivot Saw Core Cut by Diamond Products
Call for Price call for price call for price
2
2900665 Belleville Washer, 1/2" fits CC6160D by Core Cut Diamond Products
$6.99
3
2900058 Flat Washer, 1/2" SAE fits CC6160D by Core Cut Diamond Products
$6.00
4
2900239 Friction Washer, 1/2" fits CC6160D by Core Cut Diamond Products
$6.00
5
6010095 Depth Stop Knob fits CC6160D by Core Cut Diamond Products
$36.00
6
2900132 Roll Pin, 3/16" x 1-1/4" fits CC6160D by Core Cut Diamond Products
$2.99
7
2900037 Hex Nut, 1/2-13 fits CC6160D by Core Cut Diamond Products
$2.99
8
6011320 Depth Stop Cable Mount for CC6160D Rear Pivot Saw Core Cut by Diamond Products
Call for Price call for price call for price
9
2900158 Yoke, 1/2-13 for CC3500J Concrete Saw Core Cut by Diamond Products
$23.67
10
2900007 Clevis Pin, 1/2" Dia. x 1-3/8" for CC6561 Concrete Saw Core Cut by Diamond Products
$4.99
11
2900004 Cotter pin for CCE0900 Concrete Saw Core Cut by Diamond Products
$2.99
