CC7874XL Frame Components Assembly Parts

CC7874XL Frame Components Assembly Parts

  • CC7874XL Frame Components
1 1
100% genuine product
Authorised dealer
Ref. Product details Price Qty Action
1
6043272 Frame Weldment for CC7874XL Concrete Saw Core Cut by Diamond Products
$1,918.80
2
6043276 Lift Frame for CC7874XL Concrete Saw Core Cut by Diamond Products
$426.69
3
6043271 Pin, Cylinder Long for CC7874XL Concrete Saw Core Cut by Diamond Products
$6.99
4
2400615 Set Collar, 3/4" for CC7874XL Concrete Saw Core Cut by Diamond Products
$8.56
5
2900002 Flat Washer, 5/8" SAE for CC7874XL Concrete Saw Core Cut by Diamond Products
$2.99
6
2900099 Cap Screw, Hex Hd., 5/8-11 x 3-1/2" for CC7874XL Concrete Saw Core Cut by Diamond Products
$6.96
7
3200026 Water Valve, 1/2" FPT for CC7874XL Concrete Saw Core Cut by Diamond Products
$122.76
8
2900038 Lock Washer, #10 Split for CC7874XL Concrete Saw Core Cut by Diamond Products
$2.99
9
2900117 Cap Screw, Soc. Hd., #10-24 x 3/8" for CC7874XL Concrete Saw Core Cut by Diamond Products
$2.99
10
2900502 Cap Screw, Hex Hd., 5/8-11 x 5" for CC7874XL Concrete Saw Core Cut by Diamond Products
$10.76
11
3200008 Close Nipple, 1/2" NPT for CC7874XL Concrete Saw Core Cut by Diamond Products
$10.40
12
3200013 Street Elbow, 1/2" NPT for CC7874XL Concrete Saw Core Cut by Diamond Products
$13.26
13
3200022 Fitting, 1/2" F. Pipe to 3/4" F. Garden for CC7874XL Concrete Saw Core Cut by Diamond Products
$11.40
14
3200516 1/2" X 3/8" Hose Barb, 90 Deg. for CC7874XL Concrete Saw Core Cut by Diamond Products
$55.26
15
2501548 Spray Hose Assembly for CC7874XL Concrete Saw Core Cut by Diamond Products
$76.40
16
2900135 Lock Nut, 5/8-11 Nylon for CC7874XL Concrete Saw Core Cut by Diamond Products
$3.99
17
2400199 Locking Knob 3/8 Stud for CC7874XL Concrete Saw Core Cut by Diamond Products
$24.75
18
6046024 Wheel Assembly for CC7874XL Concrete Saw Core Cut by Diamond Products
Call for Price call for price call for price
19
6043240 Guide Assembly for CC7874XL Concrete Saw Core Cut by Diamond Products
$364.80
20
6046008 CC7874 Seat Group for CC7874XL Concrete Saw Core Cut by Diamond Products
$2,193.84
View full details

Frequently asked questions

How do I use this diagram?

Match the Ref. # on the diagram to the row in the parts list at the right. Click a part name to see details, price, and add it to cart.

How do I make sure a part fits my machine?

Confirm your model/series and serial number range on the product page. Many
manufacturers have serial breaks, when in doubt, share your model and serial with us and we’ll verify fit.

What do the Ref. numbers and quantities mean?

The Ref. # points to the callout on the drawing. Qty shows how many of that item your
machine uses. Parts are sold individually unless noted as a kit.

Are these genuine parts?

Yes, we supply genuine OEM parts for all our brands. If a part has an approved
replacement, we ship the latest superseded revision.

Why does my original part number look different?

Manufacturers often supersede numbers. Our pages list the current orderable number and show older numbers in the description when available. Your old number will cross-reference to the correct part.

I can’t find a part in this diagram, can you still get it?

Yes. Some items are not pictured or are shared with other assemblies. Send us the model, serial, and a description (or photo) and we’ll locate it.

Is there a warranty on these parts?

Yes. DanseUSA passes the manufacturer’s warranty to you. Coverage applies to defects in materials and workmanship under normal use for 30 days from the purchase date, in line with the manufacturer’s warranty policy. Terms can vary by brand; the product page reflects
the applicable policy. If a claim is needed, we’ll help coordinate with the manufacturer.
