CC7874XL Seat Components Assembly Parts

CC7874XL Seat Components Assembly Parts

  • CC7874XL Seat Components
1 1
100% genuine product
Authorised dealer
Ref. Product details Price Qty Action
1
6043234 Footrest Weldment Upper for CC7874XL Concrete Saw Core Cut by Diamond Products
$230.40
2
6043233 Footrest Weldment Lower for CC7874XL Concrete Saw Core Cut by Diamond Products
$385.11
3
6043236 Arm Rest Plate for CC7874XL Concrete Saw Core Cut by Diamond Products
$102.54
4
2500577 Lever, Adjustable 3/8-16" for CC7874XL Concrete Saw Core Cut by Diamond Products
$38.74
5
2900473 Flat Washer, 3/8" USS for CC7874XL Concrete Saw Core Cut by Diamond Products
$2.99
6
2900006 Lock Washer, 3/8" Split for CC7874XL Concrete Saw Core Cut by Diamond Products
$2.99
7
2900018 Lock Nut, 3/8-16 Nylon for CC7874XL Concrete Saw Core Cut by Diamond Products
$2.99
8
2501505 1/2" Handle Nut for CC7874XL Concrete Saw Core Cut by Diamond Products
$24.75
9
2501539 Arm Rest Top for CC7874XL Concrete Saw Core Cut by Diamond Products
$12.79
10
2900022 Flat Washer, 5/16" SAE for CC7874XL Concrete Saw Core Cut by Diamond Products
$2.99
11
2900005 Cap Screw, Hex Hd., 3/8-16 x 1" for CC7874XL Concrete Saw Core Cut by Diamond Products
$2.99
12
6043235 Seat Mount Weldment for CC7874XL Concrete Saw Core Cut by Diamond Products
$172.26
13
2900542 Tap Bolt, Hex Hd., 1/2-13 x 3-1/2" for CC7874XL Concrete Saw Core Cut by Diamond Products
$6.99
14
2900174 Cap Screw, Flat Hd., 5/16-18 x 1" for CC7874XL Concrete Saw Core Cut by Diamond Products
$3.99
15
2900039 Lock Nut, 5/16-18 Nylon for CC7874XL Concrete Saw Core Cut by Diamond Products
$2.99
16
2501501 Speed Control Stick for CC7874XL Concrete Saw Core Cut by Diamond Products
$726.66
17
2900294 Cap Screw, Hex Hd., 1/4-20 x 2" for CC7874XL Concrete Saw Core Cut by Diamond Products
$3.99
18
2900009 Flat Washer, 1/4" SAE for CC7874XL Concrete Saw Core Cut by Diamond Products
$2.99
19
2900010 Lock Nut, 1/4-20 Nylon for CC7874XL Concrete Saw Core Cut by Diamond Products
$2.99
20
2501547 Seat for CC7874XL Concrete Saw Core Cut by Diamond Products
$542.52
21
2505500 Vibration Isolator for CC7874XL Concrete Saw Core Cut by Diamond Products
$38.42
22
2900060 Cap Screw, Hex Hd., 3/8-16 x 2" for CC7874XL Concrete Saw Core Cut by Diamond Products
$3.99
23
2501506 Speed Control Cable for CC7874XL Concrete Saw Core Cut by Diamond Products
$431.64
View full details

Frequently asked questions

How do I use this diagram?

Match the Ref. # on the diagram to the row in the parts list at the right. Click a part name to see details, price, and add it to cart.

How do I make sure a part fits my machine?

Confirm your model/series and serial number range on the product page. Many
manufacturers have serial breaks, when in doubt, share your model and serial with us and we’ll verify fit.

What do the Ref. numbers and quantities mean?

The Ref. # points to the callout on the drawing. Qty shows how many of that item your
machine uses. Parts are sold individually unless noted as a kit.

Are these genuine parts?

Yes, we supply genuine OEM parts for all our brands. If a part has an approved
replacement, we ship the latest superseded revision.

Why does my original part number look different?

Manufacturers often supersede numbers. Our pages list the current orderable number and show older numbers in the description when available. Your old number will cross-reference to the correct part.

I can’t find a part in this diagram, can you still get it?

Yes. Some items are not pictured or are shared with other assemblies. Send us the model, serial, and a description (or photo) and we’ll locate it.
