Certified EPA/CARB Tier 4 engine
Advanced digital 7” display
Smart 3 mode display screen for blade speed, engine speed, engine torque views
Critical diagnostics functions alert potential problems to avoid shutdown
Blade over-speed alert
Engine service alerts and maintenance reminders
USB Port for quick simple updating of display software
Digital depth indicator/stop
Front View Camera to view sawing location/obstructions
LED spot and bar lights for night sawing • Adjustable blade lowering speed • Central water control valve
Auto Water System (AWS) automatically starts/stops water to blade when in/ out of cut
Quick set handlebars
On-board handlebar storage
Convenient battery access for easy charging access
Single piece frame platform with a heavy bar and tubular reinforcement
Undercarriage slurry flap to minimize slurry buildup on rear axle components
Tubular frame lift -central hoist location for balanced even lifting
Effective weight balance for balanced optimum performance
Fast attach blade guard stabilizer with quick disconnect ball joints to speed guard removal
Steady hydrostatic pump for smooth reliable response with low-speed travel creep
Heavy-duty wheels with1” thick polyurethane tread for front and rear wheels
Easy-turn 5th wheel that automatically lifts rear wheels at max raise height to allow rear saw swivel
Enclosed rear wheel motors that are hydraulically driven with center swivel for easy tracking adjustment
Simple freewheeling with dash mounted switch activation
Robust blade shaft with massive support by 3 pillow block style, spherical roller bearings
Powerful Jackshaft drive with low speed, high torque blade drive maximizing full engine power
Vast 25” depth sawing with an impressive 60” blade and 10” quick disconnect flanges
Advanced air cleaner with radial seal primary and secondary filters along with spinner style pre-cleaner
Reliable radiator fan drive with gear-driven clutch drive for strong cooling performance
Front-mounted radiator with front saw access for quick cleaning and servicing
Robust radiator core made of heavy-duty aluminum that withstands frequent power washing
Heavy rear weight kit with improved traction for the deepest sawing
Sealed electronic protection that resists heat, moisture, shock, and vibration
Corrosion-resistant components with a durable finish for harsh demanding conditions
Engine Model Kubota V3307-CR-TE4B, EPA Carb Tier 4 Final/ EU Stage III B
Engine Max. Power 74.3 hp @ 2600 rpm
Peak Torque 195.5 Ft-Lbs (265 Nm) @ 1500 rpm
Engine Sheave Size 4”
-
