594651901 Bellows for LT5005 Compaction Rammers by Husqvarna

594651901 Bellows for LT5005 Compaction Rammers by Husqvarna

Regular price $80.90
Regular price Sale price $80.90
Sale Sold out
Skip to product information
1 of 1
100% genuine product
100% genuine product
Authorised dealer
Authorised dealer
Husqvarna

594651901 Bellows for LT5005 Compaction Rammers by Husqvarna

594651901 Bellows for LT5005 Compaction Rammers by Husqvarna

Danse #: 594651901
Mfr #: 594651901
Regular price $80.90
Regular price Sale price $80.90
Sale Sold out
  • Due to uncertain tariff environment, certain dropship products may be subject to price changes post ordering.
Our Promise To You
🛠️
OEM Certified Parts
🚚
Fast Delivery
🧑‍🔧️
Expert Support
🔁
Easy Returns
🛡️
Warranty Included

Description

Husqvarna LT 5005 Rammer Leg Bellows — OEM Part 594651901

The bellows is the heavy-duty rubber accordion that surrounds the spring unit on your Husqvarna LT 5005 rammer. It seals the rammer leg from site dust, mud, and water while allowing the piston rod to compress and extend through every blow of the 11.9 Hz cycle. When the bellows splits, abrasive dust enters the spring unit and accelerates wear on the piston rod, internal springs, and seals — what starts as a $40 rubber failure ends as a full spring unit rebuild if it's left alone.

This is the genuine OEM Husqvarna replacement bellows for the LT 5005 platform, shipped in Husqvarna packaging. No aftermarket clones.

When to Replace Your LT 5005 Bellows

  • Visible cracks or splits in the rubber convolutions
  • Tearing or pulling around the upper or lower clamp area
  • Oil weeping from the rammer leg (often indicates dust intrusion has already damaged internal seals)
  • Hardening, glazing, or loss of flexibility from age, UV, or heat exposure
  • Preemptively, during a planned spring unit rebuild — replace it while the assembly is already open rather than tearing it back down later

Compatibility

Article Number Configuration
967854601 Husqvarna LT 5005, 9-in. (230 mm) foot
967854602 Husqvarna LT 5005, 6-in. (153 mm) foot


Confirm your machine's article number on the type plate (located beside the air filter housing) before ordering. The LT 6005 uses a different bellows — don't cross-order between models.

Installation Reference

  • Top and lower clamp torque: 8.4 Nm
  • Bellows orientation: wider flange seats against the upper bellows support; narrower end clamps to the outer tube
  • Surface prep: clean the bellows support and outer tube mating surfaces before installation — any debris will create a dust-ingress path
  • Access: the engine and spring unit must come off for full bellows replacement (refer to workshop manual sections 7.8.4 and 7.8.5)
  • Caution: use a soft hammer to seat the outer tube. Never strike the bellows directly with a steel hammer or pry against the rubber with a screwdriver

Pair These Parts in the Same Service Visit

If you're already inside the rammer leg, replace these at the same time:

  • 594 65 71-01 — Spring Unit Repair Kit (LT 5005 specific)
  • Top and lower bellows clamps if showing corrosion or distortion
  • 594 51 84-01 — Fiber Washer
  • 594 51 85-01 — Sight Plug
  • SAE 10W-30, API Class SJ rammer leg oil — LT 5005 capacity is 0.6 L

Why Buy From DanseUSA

  • Authorized Husqvarna construction equipment parts dealer since 1981
  • Genuine OEM packaging on every order — no aftermarket substitutes
  • Direct supplier shipping on stocked items
  • Same-day order processing on in-stock parts
  • Technical support for fitment questions and pairing recommendations

Need to Confirm Fitment?

Email [email protected] with your LT 5005 article number from the type plate, and we'll verify the bellows P/N matches your build before you order.
