Multiquip Mikasa 362910150 / KITSHOEMTX50/60 — Genuine OEM 10.4" Wood Shoe Kit (Foot Assembly 265W M4B) for MT-E55, MTX50HD, MTX60HD, MTX60HF Rammers

The shoe is the only part of a tamping rammer that touches the ground. On a Multiquip MTX-Series rammer running at full RPM, the foot strikes the substrate 644 to 695 times every minute — roughly 310,000 to 334,000 ground impacts in a single 8-hour shift. The laminated wood shoe absorbs every one of those impacts, and over time it cracks, splits, separates from its tempered-steel base plate, and walks the mounting bolts loose.

Multiquip part 362910150 — also marketed under the SKU KITSHOEMTX50/60 — is the genuine OEM 10.4-inch wood shoe kit that returns your rammer to factory-spec compaction performance. The kit fits the entire 10.4-inch-shoe MTX50/MTX60 platform and earlier MT-Series rammers, and ships complete with the laminated wood pad, the tempered steel base plate, and all mounting hardware needed for installation.

DanseUSA has been an authorized Multiquip parts dealer since 1981. Every 362910150 ships in original Multiquip packaging through authorized supply channels.

What's in the 362910150 / KITSHOEMTX50/60 Kit

Per Multiquip's MTX-Series Operation Manual, the foot construction is described as "laminated wood with tempered steel plate for superior shock absorption." The two-layer engineering protects the rest of the rammer from sharp impulse loads — the wood absorbs, the steel transmits, and the bellows-and-spring system above the foot operates within its designed loading envelope.

Multiquip designation: Foot Assembly 265W M4B (the "265W" indicates 265 mm shoe width; "M4B" is the model-version designation for this assembly).

Multi-Model Compatibility

The 10.4-inch shoe is shared across Multiquip's compact and mid-class tamping rammer platform regardless of model year or engine package. The same physical 362910150 / KITSHOEMTX50/60 kit fits all of the following:

Shoe footprint across all compatible models: 10.4 × 13.4 in (265 × 340 mm). Mounting bolt pattern, hardware grade, and base plate geometry are identical.

What 362910150 does NOT fit: This is the smaller 10.4-inch shoe kit for the MTX50/MTX60 platform. It does not fit the larger MTX70HD, MTX70HDR, MTX70HF, MTX80HDR, MTX90, or other 11-inch-shoe rammers — those use the 8511S kit instead. If you're servicing one of those models, see our 11-inch wood shoe kit page.

When to Replace the Shoe

The MTX-Series Operation Manual lists shoe inspection under daily preventive maintenance. Field signals indicating immediate replacement:

• Visible cracks running across the wood face, especially around bolt holes
• Lamination separation between wood plies
• Mushroomed or recessed bolt heads from impact loading
• Asphalt or aggregate embedded in the wood face causing imbalance
• Uneven wear pattern across the face indicating asymmetric impact distribution
• Audible change in the rammer's compaction note

Typical replacement intervals (10.4-inch shoe platform):

Universal Installation Notes

The 362910150 installs on all compatible models using the same procedure:

1. Shut down and let the foot housing cool before disassembly. Muffler heat soaks adjacent components.
2. Photograph the existing bolt orientation before removal. Square-neck bolts seat in specific orientations — reproducing the pattern from memory wastes bench time.
3. Inspect the foot housing mating surface for impact damage from the failed shoe. Address any scoring before installing the new shoe.
4. Use the OEM hardware that ships with the kit. Square-neck bolts in the 362910150 are graded for the impact regime; substituting hardware-store bolts is the most common cause of premature loosening.
5. Torque in cross-pattern sequence for even preload distribution.
6. Re-torque after 30 minutes, 4 hours, and 24 hours of run time. Bolt preload migrates during the first day under impact loading.

Part Identification & Cross-Reference

Frequently Asked Questions

Q: What's the difference between 362910150 and KITSHOEMTX50/60? The two part numbers reference the same physical product. 362910150 is the engineering/parts-manual designation; KITSHOEMTX50/60 is Multiquip's marketing SKU for the same kit. Both ship the same shoe, steel plate, and hardware.

Q: Will this fit my Multiquip rammer? The 362910150 fits all 10.4-inch-shoe MTX-Series rammers (MTX50HD, MTX60HD, MTX60HF) plus legacy MT-Series rammers (MT-E55, MT54F, MT55F, MT60, DR-50, older MTX60). It does not fit the larger MTX70/MTX80/MTX90 platform — those use the 11-inch 8511S kit.

Q: Does the kit come with bolts, washers, and nuts? Yes. The OEM kit ships with all mounting hardware required for installation — seven 10×55 mm square-neck bolts, seven M10 lock washers, and seven M10 nylon lock nuts.

Q: What is "Foot Assy 265W M4B"? That's Multiquip's internal designation for this assembly. "265W" refers to the shoe width in millimeters (265 mm = 10.4 inches); "M4B" is the model-version designation. It's the same product as part 362910150.

Q: How long should the wood shoe last? Typical commercial use ranges from 6 to 14 months depending on rammer model and substrate hardness. Inspect daily and replace at the first sign of cracking, lamination separation, or bolt-head deformation.

Q: How is the wood shoe constructed? Per Multiquip's Operation Manual, the foot is "laminated wood with tempered steel plate for superior shock absorption." The wood pad is a multi-ply laminate engineered to absorb impact progressively rather than transmitting a sharp impulse to the bellows and spring components above. The steel plate provides the structural interface to the rammer foot housing.

Q: Will replacing the shoe void my Multiquip warranty? No. Replacing wear components like the shoe is normal preventive maintenance and does not affect warranty terms. Using the genuine OEM 362910150 keeps the rammer in factory-spec configuration.

Q: How is the 362910150 shipped? DanseUSA ships in original Multiquip packaging via standard ground service. Some MTX-Series components may ship from Multiquip's distribution warehouse direct — when that happens, your order may arrive in separate packages with individual tracking numbers.

Important Ordering Notes

• Make sure the part numbers are correct, certain parts are serial number specific. The MTX-Series has been through multiple production revisions — verify your machine's serial plate matches the model designation before ordering.
• Contact us for parts identification and confirmation of part numbers. Email [email protected] with photos of your engine label, serial plate, and existing shoe assembly. Same-business-day verification on all parts inquiries.
• Certain items may be drop shipped direct from the manufacturer. Your order may arrive in separate packages with individual tracking numbers.

Why Order from DanseUSA

Authorized Multiquip parts dealer since 1981. Every 362910150 / KITSHOEMTX50/60 ships in original Multiquip packaging through authorized supply channels — same OEM part the local Multiquip-authorized service center installs, eligible for any open Multiquip warranty on your rammer.

Most orders placed before noon ET ship the same business day. Questions on fitment, serial-number breaks, or fleet pricing? Email [email protected] with photos of your unit and existing shoe assembly for same-business-day verification.
