8511S 11" Laminated Wood Shoe Kit for Multiquip Mikasa MTX70HF Tamping Rammer

8511S 11" Laminated Wood Shoe Kit for Multiquip Mikasa MTX70HF Tamping Rammer

Regular price $399.00
Regular price Sale price $399.00
Sale Sold out
Skip to product information
1 of 1
100% genuine product
100% genuine product
Authorised dealer
Authorised dealer
MultiQuip

8511S 11" Laminated Wood Shoe Kit for Multiquip Mikasa MTX70HF Tamping Rammer

8511S 11" Laminated Wood Shoe Kit for Multiquip Mikasa MTX70HF Tamping Rammer

Danse #: 8511S
Mfr #: 8511S
Regular price $399.00
Regular price Sale price $399.00
Sale Sold out
  • Due to uncertain tariff environment, certain dropship products may be subject to price changes post ordering.
Our Promise To You
🛠️
OEM Certified Parts
🚚
Fast Delivery
🧑‍🔧️
Expert Support
🔁
Easy Returns
🛡️
Warranty Included

Description

The Multiquip MTX70HF is the lower-impact legacy variant of the MTX70 platform — Honda GX100UKRB5 engine, 2,855 lbf of impact force, 163 lbs operating weight, and the same 11.2 × 13.4 inch shoe footprint shared across the MTX70/80/90 series. Production of the HF preceded the current HD/HDR models (Operation Manual Rev. #0 dated 03/08/12), and well-maintained units remain in service across utility, landscaping, and municipal-works fleets nationwide.

For fleet managers maintaining MTX70HF inventory, the wood shoe is the consumable wear part — the only component that needs scheduled replacement during the rammer's serviceable life. Multiquip part 8511S is the genuine OEM 11-inch wood shoe kit that fits the MTX70HF foot mount in direct factory configuration.

What ships in the 8511S kit

The kit is a complete shoe-replacement bundle, not just a wood pad. Per Multiquip's parts catalog, 8511S ships with:

  1. The laminated multi-ply wood shoe pad — the ground-contact wear surface
  2. The tempered steel base plate that bonds the wood pad to the rammer foot housing
  3. Square-neck mounting bolts (for the through-bolt connection)
  4. Lock washers (M10 and M12 grades, depending on mount position)
  5. Nylon lock nuts for vibration retention

This is the same kit that ships from the factory on a new MTX70HF. Ordering 8511S means you don't need to source replacement bolts separately, and the bolt grade matches the impact loading the rammer was engineered for.

MTX70HF Reference Specifications

Parameter MTX70HF Value
Operation Manual Issue Rev. #0 (March 2012)
Engine Honda GX100UKRB5
Engine Type Air-cooled 4-stroke OHC, single cylinder
Engine Displacement 98 cc (6.0 cu.in.)
Engine Output 3.0 hp / 3,600 rpm (2.2 kW)
Impact Force 2,855 lbf (12.7 kN)
Impact Plate Stroke 2.0 – 3.2 in (50 – 80 mm)
Impacts per Second 10.7 – 11.5
Shoe Footprint 13.4 × 11.2 in (340 × 285 mm)
Operating Weight 163 lbs (74 kg)
Replacement Shoe Kit 8511S (this part)


Why the MTX70HF wood shoe is a maintenance item, not an emergency repair

The MTX70HF Operation Manual lists the shoe under "Daily Inspection" — operators are instructed to inspect the foot for cracks, loose hardware, and impact damage before every shift. Multiquip's preventive-maintenance posture treats the shoe as a scheduled-replacement component, not a run-to-failure part.

A worn shoe on the MTX70HF specifically:

  • Reduces effective compaction force below the rated 2,855 lbf
  • Transmits asymmetric impact loads into the bellows and spring cylinder above
  • Risks foot housing damage if a bolt failure allows the steel plate to shift under load
  • Can crack adjacent rubber bellows components from imbalanced operating geometry

Replacing the shoe before any of those secondary failures occurs is the lowest-cost maintenance posture for an MTX70HF over its remaining service life.

Frequently Asked Questions — MTX70HF Wood Shoe

Q: Multiquip stopped making the MTX70HF — are parts still available? Yes. Multiquip maintains active OEM parts inventory for the MTX70HF, including the 8511S wood shoe kit. The 11-inch shoe is shared across multiple models (MTX70HD, MTX70HDR, MTX80HDR), so production volume keeps the part in regular stock.

Q: Will an aftermarket shoe work on my MTX70HF? Aftermarket 11-inch shoes are sold by multiple suppliers, but quality varies significantly. The OEM 8511S meets factory tolerances on bolt-hole alignment, wood lamination grade, and steel plate temper. For an MTX70HF that needs to remain in productive service, OEM is the lower-risk option.

Q: My MTX70HF predates the current part-number system — what was the original shoe kit number? The 8511S supersedes legacy Multiquip part numbers 366910020 and 362910130. If your service records reference either older number, the 8511S is the direct replacement.

Q: Is the wood pad warranty-eligible if it cracks within the first 90 days? Multiquip warranty terms vary by component and original purchase circumstances. For warranty inquiries on an OEM 8511S installed on an MTX70HF, contact us with your purchase information and we'll route it through the appropriate channel.

Important Ordering Notes

  • Make sure the part numbers are correct, certain parts are serial number specific. The MTX70HF predates the HD redesign — confirm your serial plate before ordering.
  • Contact us for parts identification and confirmation of part numbers. Email [email protected] with photos of your engine label, serial plate, and existing shoe assembly. Same-business-day verification.
  • Certain items may be drop shipped direct from the manufacturer. Orders may arrive in separate packages with individual tracking numbers.
