8511S Multiquip OEM 11" Wood Shoe Kit — Fits MTX80HDR Tamping Rammer (Honda GXR120)

8511S Multiquip OEM 11" Wood Shoe Kit — Fits MTX80HDR Tamping Rammer (Honda GXR120)

Regular price $399.00
Regular price Sale price $399.00
Sale Sold out
Skip to product information
1 of 1
100% genuine product
100% genuine product
Authorised dealer
Authorised dealer
MultiQuip

8511S Multiquip OEM 11" Wood Shoe Kit — Fits MTX80HDR Tamping Rammer (Honda GXR120)

8511S Multiquip OEM 11" Wood Shoe Kit — Fits MTX80HDR Tamping Rammer (Honda GXR120)

Danse #: 8511S
Mfr #: 8511S
Regular price $399.00
Regular price Sale price $399.00
Sale Sold out
  • Due to uncertain tariff environment, certain dropship products may be subject to price changes post ordering.
Our Promise To You
🛠️
OEM Certified Parts
🚚
Fast Delivery
🧑‍🔧️
Expert Support
🔁
Easy Returns
🛡️
Warranty Included

Description

The MTX80HDR is the largest, heaviest, and highest-impact rammer in Multiquip's current MTX-Series lineup. 3,505 lbf of impact force, an 11.2-inch shoe, 181 lbs of operating weight, and the high-output Honda GXR120 engine. Operators reach for it on jobs nothing smaller will close: deep-trench cohesive backfill, oversized embankment lifts, heavy-clay foundation prep, and high-volume site work where a smaller rammer would need to make a second or third pass.

That maximum-impact duty cycle has a direct consequence for the wood shoe: the MTX80HDR wears its shoe faster than any other MTX rammer. Higher impact force per blow, heavier machine pressing the shoe into the substrate, and longer continuous run times all compound. Operators on MTX80HDR units typically replace the shoe 30–40% more often than crews running an MTX70HD on comparable applications.

Multiquip part 8511S is the genuine OEM 11-inch wood shoe kit, factory-engineered for the impact loading the MTX80HDR generates.

The Operation Manual describes the foot construction as "laminated wood with tempered steel plate for superior shock absorption." That two-layer engineering matters most on the MTX80HDR — at 3,505 lbf, the impact transmitted through the shoe to the bellows and spring cylinder above must be progressively absorbed, not delivered as a sharp impulse. A factory-spec wood pad provides the absorption profile the rest of the rammer was designed to operate against.

MTX80HDR Specifications

Parameter Value
OEM Shoe Part Number 8511S
Legacy / Superseded Numbers 366910020, 362910130
Shoe Width 11 in
Engine Honda GXR120 (high-output OHC)
Impact Force 3,505 lbf (1,590 kgf)
Operating Weight 181 lbs (82 kg)
Position in MTX Lineup Largest current model
Hardware Included Yes (bolts, washers, nuts)
Best Application Heavy-duty deep-trench compaction, large embankments

Heavy-Duty Installation Notes

The MTX80HDR's higher impact loading means the shoe-mount bolt joint sees more peak stress per cycle than any other MTX model. Three points to watch on installation:

  • Use the supplied OEM hardware, not aftermarket bolts. The square-neck bolts in the 8511S kit are graded for the MTX80HDR's impact regime; substituting hardware-store bolts is the most common cause of premature loosening on this machine.
  • Re-torque after the first 30 minutes of operation, then again after 4 hours, then again at the 24-hour mark. After that, the joint will have settled.
  • Inspect the foot housing mating surface for impact damage from the failed shoe. On an MTX80HDR specifically, a worn shoe that's been run too long can score the housing — if you see scoring, address it before installing the new shoe to prevent recurring premature failure.

Frequently Asked Questions — MTX80HDR Wood Shoe

Q: How often should I replace the wood shoe on an MTX80HDR? For typical commercial use, every 4 to 9 months depending on substrate hardness and run-hours. Crews running MTX80HDR units on heavy-clay or rocky-fill applications wear shoes faster than crews working softer cohesive soils. Visual inspection daily — replace at first sign of cracking, lamination separation, or bolt-head mushrooming.

Q: Is the 8511S the same as the MTX70HD shoe kit? Yes — physically identical. Multiquip uses the 11-inch wood shoe across the entire MTX70/MTX80 platform (and MTX90 legacy). The same 8511S OEM kit fits MTX70HD, MTX70HDR, MTX70HF, and MTX80HDR. The shoe is shared even though the engines, weights, and impact forces differ.

Q: Does the higher impact force of the MTX80HDR damage shoes faster? Yes — proportional to impact loading. The MTX80HDR's 3,505 lbf delivers about 4.6% higher impact force than the MTX70HD's 3,350 lbf, but the heavier operating weight (181 lbs vs ~168 lbs) compounds the effect. In practice, MTX80HDR shoe replacement intervals run 30–40% shorter than MTX70HD intervals on the same job mix.

Q: Can I substitute an aftermarket 11-inch wood shoe? Aftermarket shoes from various Amazon and eBay suppliers are physically dimensioned to match the OEM 8511S, but tolerance accuracy, wood lamination grade, and bolt-hole alignment vary by manufacturer. For an MTX80HDR specifically, the higher impact loading punishes any tolerance slop in the shoe assembly — OEM is the lower-risk choice for fleet operators where downtime is the larger cost.

Important Ordering Notes

  • Make sure the part numbers are correct, certain parts are serial number specific. Confirm your MTX80HDR's serial plate matches the part designation before ordering.
  • Contact us for parts identification and confirmation of part numbers. Send [email protected] photos of your engine label, serial plate, and existing shoe assembly for verification.
  • Certain items may be drop shipped direct from the manufacturer. Your order may arrive in separate boxes — each with individual tracking.
