Ref.
Details
1
2702046 Motor case for DK52 WEKA Core Cut by Diamond Products
$384.00
2
2702041 Intermediate Flange for DK52 WEKA Core Cut by Diamond Products
Call for Price
3
2701377 Motor Top Hood for DK52 WEKA Core Cut by Diamond Products
$172.80
4
2702047 Case Sleeve for DK52 WEKA Core Cut by Diamond Products
$254.40
5
2700834 Terminal Case Cover for DK52 WEKA Core Cut by Diamond Products
$32.36
6
2702048 Rotor with Bearings for DK52 WEKA Core Cut by Diamond Products
$494.40
7
2702050 Stator 230V/60Hz for DK52 WEKA Core Cut by Diamond Products
$1,022.40
13
2701071 Cord Angle with O-Ring for DK52 WEKA Core Cut by Diamond Products
$42.89
15
2701040 Terminal Case Insulation for DK52 WEKA Core Cut by Diamond Products
$8.08
16
2704245 Carrying Handle for DK52 WEKA Core Cut by Diamond Products
$22.01
17
2701041 Rotary Shaft Seal 20x32x7 for DK52 WEKA Core Cut by Diamond Products
$17.06
18
2701080 Terminal Case Sealing for DK52 WEKA Core Cut by Diamond Products
$5.60
20
2701043 Ball Bearing 6202 ZZ for DK52 WEKA Core Cut by Diamond Products
$23.29
21
2701044 Ball Bearing 6004 ZZ for DK52 WEKA Core Cut by Diamond Products
$26.63
22
2701045 Compensation Washer for DK52 WEKA Core Cut by Diamond Products
$4.97
23
2701046 O-Ring RDR 135x2 for DK52 WEKA Core Cut by Diamond Products
$6.70
24
2701047 O-Ring RDR 127x4 for DK52 WEKA Core Cut by Diamond Products
$5.57
25
2701048 O-Ring RDR 11x2,5 for DK52 WEKA Core Cut by Diamond Products
Call for Price
26
2701049 Hex. Soc. Head Screw M6x20 for DK52 WEKA Core Cut by Diamond Products
$2.11
27
2700852 Hex. Soc. Head Screw M6x35 for DK52 WEKA Core Cut by Diamond Products
$1.99
161
2700852 Hex. Soc. Head Screw M6x35 for DK52 WEKA Core Cut by Diamond Products
$1.99
28
2701388 Fill. Head Screw M4x12 for DK52 WEKA Core Cut by Diamond Products
$1.99
76
2701388 Fill. Head Screw M4x12 for DK52 WEKA Core Cut by Diamond Products
$1.99
31
2700674 Slot. Pan Head Screw M4x6 for DK52 WEKA Core Cut by Diamond Products
$1.99
34
2701399 Round Head Grooved Pin 2,3x4 for DK52 WEKA Core Cut by Diamond Products
Call for Price
36
2702372 Sealing Washer 6 for DK52 WEKA Core Cut by Diamond Products
$1.99
38
2700680 Curved Spring Washer A4 for DK52 WEKA Core Cut by Diamond Products
$1.99
39
2700681 Medium Washer 4.3 for DK52 WEKA Core Cut by Diamond Products
$1.99
44
2701568 O-Ring 18x2 for DK52 WEKA Core Cut by Diamond Products
$1.99
45
2701451 Cord Gland 230V for DK52 WEKA Core Cut by Diamond Products
$12.55
83
2701451 Cord Gland 230V for DK52 WEKA Core Cut by Diamond Products
$12.55
46
2701074 Hexagon Nut M20x1,5 for DK52 WEKA Core Cut by Diamond Products
$7.48
47
2706091 Terminal for DK52 WEKA Core Cut by Diamond Products
$21.58
49
2706088 Double Press Key for DK52 WEKA Core Cut by Diamond Products
$82.20
50
2706089 Switch Element for DK52 WEKA Core Cut by Diamond Products
$71.60
51
2702051 Cord 480V AWG 18/7 for DK52 WEKA Core Cut by Diamond Products
$90.34
51
2701381 Cord 230V AWG 16/7 for DK52 WEKA Core Cut by Diamond Products
$92.74
52
2706090 Key Diaphragm for DK52 WEKA Core Cut by Diamond Products
$30.25
55
2700715 Ball Valve for DK52 WEKA Core Cut by Diamond Products
$32.95
56
2700925 Grip for Ball Valve for DK52 WEKA Core Cut by Diamond Products
Call for Price
59
2700717 Sealing Ring G 1/4" for DK52 WEKA Core Cut by Diamond Products
$3.99
60
2700716 Double Nipple G 1/4" for DK52 WEKA Core Cut by Diamond Products
$13.81
62
2701060 Flexible Hose for DK52 WEKA Core Cut by Diamond Products
$5.45
65
2701094 Angle Screwing G 1/4" for DK52 WEKA Core Cut by Diamond Products
$22.91
67
2800412 Plug USA (not pictured) 460V for DK52 WEKA Core Cut by Diamond Products
Call for Price
67
2800162 Plug USA (not pictured) 230V for DK52 WEKA Core Cut by Diamond Products
$37.70
75
2701401 Cablecase cpl. w- Fig.83, 85 w/o Fig. 79, 80 for DK52 WEKA Core Cut by Diamond Products
$163.20
77
2700677 Hexagon Nut M4 for DK52 WEKA Core Cut by Diamond Products
$1.99
79
2701403 Contactor 460V for DK52 WEKA Core Cut by Diamond Products
$163.20
79
2702055 Contactor 230V for DK52 WEKA Core Cut by Diamond Products
$412.80
80
2701579 Print Plate without Contactor 460V for DK52 WEKA Core Cut by Diamond Products
$162.00
80
2701580 Print Plate w/o Cont. DK42A 230V for DK52 WEKA Core Cut by Diamond Products
$160.80
80
2702056 Print Plate w/o Cont. DK52 230V for DK52 WEKA Core Cut by Diamond Products
$163.20
85
2701405 Tapping Screw 4,8x32 for DK52 WEKA Core Cut by Diamond Products
$1.99
86
2701581 Fuse 32 mA mT for DK52 WEKA Core Cut by Diamond Products
$5.26
87
2707169 Cord 4G1,5x0,5 for DK52 WEKA Core Cut by Diamond Products
$33.32
90
2701924 Gear Box for DK52 WEKA Core Cut by Diamond Products
$409.20
91
2700871 Water Supply Bush for DK52 WEKA Core Cut by Diamond Products
$94.47
92
2700872 Gear Change Grip for DK52 WEKA Core Cut by Diamond Products
$65.69
93
2701925 Gear Change Lever for DK52 WEKA Core Cut by Diamond Products
$31.61
94
2701926 Spindle cpl. w- fig. 106+142 for DK52 WEKA Core Cut by Diamond Products
$295.20
95
2702052 Gear Change Shaft for DK52 WEKA Core Cut by Diamond Products
$194.40
95
2700875 Gear Change Shaft S for DK52 WEKA Core Cut by Diamond Products
$171.60
96
2701928 Pinion Shaft for DK52 WEKA Core Cut by Diamond Products
$250.80
97
2702053 Spur Wheel for DK52 WEKA Core Cut by Diamond Products
$86.63
98
2701930 Gear Wheel 1 for DK52 WEKA Core Cut by Diamond Products
$147.60
99
2701931 Gear Wheel 3 for DK52 WEKA Core Cut by Diamond Products
$112.22
100
2701932 Slide Gear Wheel for DK52 WEKA Core Cut by Diamond Products
$176.40
101
2702145 Spindle Wheel for DK52 WEKA Core Cut by Diamond Products
$151.20
101
2702146 Spindle Wheel S for DK52 WEKA Core Cut by Diamond Products
$159.60
101
2707788 Spindle Wheel HS for DK52 WEKA Core Cut by Diamond Products
$152.40
103
2701083 Supporting DisK for DK52 WEKA Core Cut by Diamond Products
$21.11
104
2701934 Brake Disk A for DK52 WEKA Core Cut by Diamond Products
$23.99
105
2701935 Pressure Disk for DK52 WEKA Core Cut by Diamond Products
$27.08
106
2701064 Protective Sleeve for DK52 WEKA Core Cut by Diamond Products
$17.08
107
2701941 Brake Disk B for DK52 WEKA Core Cut by Diamond Products
$30.88
109
2702054 Pressure Ring for DK52 WEKA Core Cut by Diamond Products
$17.26
112
2706123 Feed Worm for DK52 WEKA Core Cut by Diamond Products
$31.99
119
2701370 Needle Bearing for DK52 WEKA Core Cut by Diamond Products
$48.42
120
2700791 Ball Bearing 6302 for DK52 WEKA Core Cut by Diamond Products
$31.84
121
2700792 Ball Bearing 6201 for DK52 WEKA Core Cut by Diamond Products
$34.51
123
2700794 Needle Bush for DK52 WEKA Core Cut by Diamond Products
$25.90
124
2700795 Needle Bush for DK52 WEKA Core Cut by Diamond Products
$31.03
125
2700796 Thrust Ball Bearing for DK52 WEKA Core Cut by Diamond Products
$71.20
126
2700797 Thrust Needle Cage for DK52 WEKA Core Cut by Diamond Products
$7.82
127
2700798 Thrust Bearing Washer for DK52 WEKA Core Cut by Diamond Products
$8.08
128
2700799 O-Ring RDR102x3 for DK52 WEKA Core Cut by Diamond Products
$5.40
129
2700711 O-Ring RDR20x3 for DK52 WEKA Core Cut by Diamond Products
$1.99
131
2700802 Rotary Shaft Seal 40x52x7 for DK52 WEKA Core Cut by Diamond Products
$27.44
132
2700803 Rotary Shaft Seal 38x50x7 for DK52 WEKA Core Cut by Diamond Products
$22.22
133
2700804 Rotary Shaft Seal 40x52x7S for DK52 WEKA Core Cut by Diamond Products
$27.38
140
2700809 Disc Spring for DK52 WEKA Core Cut by Diamond Products
$5.65
141
2700810 Pressure Spring for DK52 WEKA Core Cut by Diamond Products
$3.65
142
2700811 Ball 5 for DK52 WEKA Core Cut by Diamond Products
$1.99
143
2700720 Ball 4 for DK52 WEKA Core Cut by Diamond Products
$1.99
144
2700813 Parallel Key A6x6x45 for DK52 WEKA Core Cut by Diamond Products
$2.71
146
2700815 Parallel Key A4x4x10 for DK52 WEKA Core Cut by Diamond Products
$2.21
147
2700816 Parallel Pin 6m6x10 for DK52 WEKA Core Cut by Diamond Products
$1.99
148
2701065 Parallel Pin 5m6x15 for DK52 WEKA Core Cut by Diamond Products
$1.99
149
2700723 Parallel Pin 3m6x16 for DK52 WEKA Core Cut by Diamond Products
$1.99
150
2700819 Shim Ring PS14x20x1 for DK52 WEKA Core Cut by Diamond Products
$1.99
151
2700820 Retaining Ring 16x1 for DK52 WEKA Core Cut by Diamond Products
$1.99
152
2700821 Retaining Ring SW20 for DK52 WEKA Core Cut by Diamond Products
$1.99
160
2700822 Hexagon Nut M22x1,5 for DK52 WEKA Core Cut by Diamond Products
$16.26
162
2702985 Hex. Soc. Head Screw M5x12 for DK52 WEKA Core Cut by Diamond Products
Call for Price
163
2700825 Hex. Soc. Head Screw M5x45 for DK52 WEKA Core Cut by Diamond Products
$2.14
164
2700826 Locking Washer SM6 for DK52 WEKA Core Cut by Diamond Products
$1.99
165
2700735 Locking Washer SM5 for DK52 WEKA Core Cut by Diamond Products
$1.99
170
2707792 Adhesive Rotation Arrow for DK52 WEKA Core Cut by Diamond Products
Call for Price
170
2701067 Gear Oil 450 ml for DK52 WEKA Core Cut by Diamond Products
$23.15
175
2705402 Antifriction-Element for DK52 WEKA Core Cut by Diamond Products
$128.40
176
2701866 O-Ring 32x1,5 for DK52 WEKA Core Cut by Diamond Products
$1.99
57
2700706 Quick Connect Nipple for DK22 WEKA Core Cut by Diamond Products
$29.42
