M-2 Core Drill Rig and OEM Parts by Core Bore Diamond Products

The M-2 core drill rig from the Core Bore line of Diamond Products is a heavy duty concrete coring stand designed for professional contractors. A rigid chrome plated mast, four spoke feed handle, leveling screws, and large wheels give you a stable platform that is still easy to move around the job. With the right Core Bore drill motor and diamond core bits it becomes a versatile diamond core drill rig for angle holes in concrete, block and similar materials.

Contractors use the M-2 as an everyday concrete core drill rig for coring and as a compact core drill rig when space is tight. Combination, vacuum, and anchor base options let you mount the stand with anchors or with a vacuum pump on flat slabs, and optional quick disconnect motor mounts and outriggers help support larger bit sizes on demanding jobs.

This collection on DanseUSA.com focuses on the genuine OEM parts that keep that stand working the way it was designed. As an authorized Core Bore Diamond Products dealer, we stock and dropship factory original M-2 core drill rig spare parts: bases, masts, roller carriages, control boxes, vacuum hardware, wheels, and the small fasteners that hold everything together.

Every part listed here is matched to the M-2 Core Bore. Using original components protects your Core Bore drill motor, keeps the mast straight and the carriage feeding smoothly and helps prevent downtime on jobs where your core bore drilling setup has to keep moving.

To find exactly what you need, you can also use the Search by Brand, Type, and Model tool at the top of the page to select Core Bore and your drill model, then open the M-2 shop by diagram pages and match the reference numbers to the listings below before you order.

What the M-2 core drill rig parts collection covers

This M-2 collection is organized to make it easy to identify and order the exact assemblies and components for your M-2 Core Drill Rig:

• Bases and stands: M-2 angle combination base, small anchor, web anchor, and angle anchor base assemblies for anchored or ceiling jack style setups. For example, many customers start with the M-2 Angle Combination Base Assembly or the M-2 Combination Base Assembly when rebuilding a worn stand.
• Masts and gear racks: straight and angle masts with gear racks in multiple lengths to match your preferred drilling reach on concrete core drill rigs, from shorter compact core drill rig setups to tall wall and column coring.
• Carriage and feed system: roller carriage assemblies, side and adjustable rollers, pinion gears, shims, and keys that keep feed smooth and accurate during Core Bore drilling. The M-2 Roller Carriage Assembly is a common replacement when feed motion starts to feel rough or uneven.
• Quick disconnect and outriggers: quick disconnect motor mount plates, adapter plates, and outrigger extensions that help you swap between stands or stabilize the rig on challenging slabs. Assemblies like the M-2 Quick Disconnect Plate Assembly make it faster to move your Core Bore drill between rigs.
• Vacuum pump and water control: M-2 vacuum platform, gaskets, complete vacuum pump assembly, water jar assembly, float ball, fittings, and muffler for vacuum mounting and water management. The M-2 Vacuum Pump Assembly 115V Parts page brings together the pump, jar, fittings, and seals in one diagram.
• Wheels, braces, and hardware: wheel assemblies, upper and lower braces, support tubes, bolts, nuts, washers, bushings, and collars that tie the entire rig together so the stand rolls easily yet locks down solidly when you start drilling.

If you are running an M-2 stand alongside a hydraulic core drilling rig or other concrete core drill rigs, keeping the OEM parts fresh helps the whole setup stay aligned and safe on the job.

Popular M-2 core drill rig replacement parts

Some of the most common items contractors order from this M-2 parts collection include:

• Vacuum and mounting components: Essential pieces that keep your vacuum mounted M-2 stand sealed to the slab, such as the 2700164 Gauge, Vacuum and the 4641024 M-2 Vacuum Gasket.
• Carriage and feed parts: Components that control how smoothly the carriage feeds your core drill into concrete, including the 4641022 Pinion Gear along with side rollers, plastic feed rollers, and carriage hardware.
• M-2 bases, shims, and wheel hardware: Anchor and combination bases, shims, and wheel assemblies that keep the stand stable, square, and easy to move around the job site, including the 4641075 M-2 Combination Base and the 4645046 Wheel Assembly.
• Control box and electrical components: Parts that support safe power delivery and monitoring for your core drill motor, including the 2800558 Amp Meter 115V 0-30 Amp, along with control boxes, line cords, toggle switches, and flanged outlets.

All of these are genuine Core Bore M-2 core drill rig spare parts, selected to match this specific equipment.

Need parts for other Core Bore concrete drill rigs?

If your fleet includes other Core Bore core drill in addition to the M-2, you can also browse:

• M-1 Core Drill Rig Parts by Core Bore Diamond Products
• M-3 Core Drill Rig Parts by Core Bore Diamond Products
• M-5 Core Rig Parts by Core Bore Diamond Products

Together with this page, these collections let you buy Core Bore Diamond core drilling parts online for the rigs you rely on, from stands and control boxes to matching Core Bore drill motors and diamond core bits.

M-2 core drill rig parts FAQs

Do these parts fit other Core Bore core drill rigs?

Most items here are specific to the M-2 stand. While some small hardware (like bolts or washers) may overlap with the M-1, M-3 or M-5 rigs. Always confirm by part number or diagram before ordering if you are unsure.

Which M-2 parts usually wear out or get replaced most often?

Contractors most often replace carriage and rolling parts like the 4647100 Roller Carriage and 4647115 Plastic Roller, vacuum and water components such as the 2700171 Water Jar Assembly.

What if I cannot find the M-2 part number I am looking for?

If a part number is missing, email photos of your equipment number and the part you need to customerservice@danseusa.com and we can help you match the correct Core Bore replacement.
